12 Volt Motor, 31ZY Permanent Magnet Generator DC Motor 4000rpm High Speed CW/CCW High Speed Motor, High DC Motor for DIY Generator

Features:It adopts precision machining, magnetic material treatment, and insulation treatment, features stable and .This DC motor features large moment of force, and low noise, The motor is made of metal gear, wear-resisting, avoid tooth breaking, so with long serving life.This DC motor supports clockwise and counterclockwise rotation.This motor is adopted of pure copper wire coil, with low heat and low loss.Specifications:Model: 31ZYOuter diameter: 31mm / 1.22inShaft length: 19mm / 0.75inShaft diameter: 3mm / 0.12inType(Optional): 6V 4000rpm,12V 4000rpm,12V 8000rpm, 24V 3500rpm, 24V 5000rpm, 24V 8000rpmWeight:165gWiring:CW: red: "+", black: "-"CWW: red: "-", black: "+"Working voltage V(Optional) 6V 12V 12V 24V 24V 24VNo-load current mA 180 350 110 200 20041No-load speed rpm 4000 8000 4000 5000 8000 3500Rated moment of force gf.cm 100 200 100 200 200 150Rated speed rpm 3200 6500 3200 4000 6600 2500Rated current A 0.8 1.6 0.5 0.6 1.0 0.3Locked-rotor moment of force gf.cm 500 1000 600 850 1200 400Locked-rotor current A 3.3 6.5 2.3 2.0 4.4 0.8Package includes: 1 x MotorPackage List：1 x Motor

• HIGH SPEED AND NO NOISE - High DC motor has high speed and high ; motor voltage 12-24V can output the speed and according to the voltage you choose; with super smooth drive characteristics, almost no noise, super load work, like the refrigerator work hum is still small
• MADE OF PURE COPPER WIRE - The stator winding of the small brushed permanent magnet 12 volt motor is made of pure copper wire, low heat generation, low loss, long life, cw/ccw can be realized by switch control (without switch). An external DC controller must be connected, which can realize the function of speed control
• SAFETY AND RELIABILITY - This permanent magnet generator adopts preciseness machining, magnetic material treatment, insulation treatment, safety, and use. If this synchronous motor works under rated frequency, speed will not affected by voltage, very stable
• HIGH-SPEED MOTOR DETAILS - Outer diameter: 31mm / 1.22in, Shaft length: 19mm / 0.75in, Shaft diameter: 3mm / 0.12in. Type(Optional): 6V 4000rpm,12V 4000rpm,12V 8000rpm, 24V 3500rpm, 24V 5000rpm, 24V 8000rpm
• WIDE APPLICATION - 12V/24V CW/CCW permanent magnet dc motor for cotton candy machines, small cutting tables, grinding machines, medical equipment, and other 12V/24V CW/CCW DIY generators
